Tuote-edut

• System+ Guarantee available
• Easy integration in luminaire thanks to same dimensions like DALI GI ECG
• TouchDIM function for easy and inexpensive dimming of several ECGs
• Same luminous flux with direct and alternating current
• Dimming of amalgam lamps without flickering or reduced lifespan
• Automatic restart after lamp replacement
DALI product features

• Control via the DALI interface
• Compliance with the DALI Version-1 and IEC 60929
• Control input protected against overvoltage and polarity reversal (OSRAM ECG)
Touch DIM and Touch DIM Sensor function

• Manual dimming without controller and with standard switches
• Including memory function (double click) and soft start

Käyttökohteet

• Suitable for use in emergency lighting systems as per EN 50172/DIN VDE 0108-100
• Installation in emergency lighting systems according to IEC 61347-2-3, appendix J
• Industry
• Open-plan offices, corridors and storage rooms
• Public buildings
• Sports halls and factories
• Strip lighting
• Suitable for luminaires of protection class I

Tuoteominaisuudet

• Corridor function for direct connection of ECG to common motion sensor
• Corridor function with pre-programmed light program
• Touch DIM function for free parameterization of light value and turn on time
• Fit for SMART GRID for feedback of consumed mains power and lamp operating hours
• Fit for emergency function for automatic detection of emergency lighting by ECG
• Very low standby power consumption: < 0.5 W
• Lifetime: > 100,000 h (for T = 65 °C at T_c)
• Very high number of switching cycles: up to 300,000
• Dimming range: 1…100 % (3…100 % with compact fluorescent lamp)
• POWER2LAMP function for optimal matching of ECG power to lamp during lamp lifetime
• Line frequency: 0 Hz, 50…60 Hz, rectified AC

Referenssit ja linkit

• Katso lisätietoja järjestelmätakuusta sekä sen ehdoista osoitteesta www.ledvance.com/system-guarantee
